LG ICR18650E1 Lithium-ion Cells
The LG ICR18650E1 is a High voltage 18650 rechargeable li-ion battery cell manufactured by LG Chem, featuring a nominal capacity of 3200mAh and 4.35V charge.
Items
Specifications
Notes
Nominal capacity
3200mAh
0.2C discharge, 2.75V cut-off
Nominal voltage
3.75V
0.2C discharge
Nominal energy
12.0Wh
Capacity(Ah) × Voltage(V)
Charging voltage
4.35 ± 0.05V
Charging current
930mA 丨1550mA
Standard丨Rapid
Charging time
4.5 hours 丨3.5 hours
Standard丨Rapid
Charging method
CC - CV
Constant current, constant voltage
Continuous discharge current
620mA 丨4650mA
Standard丨Maximum
Peak discharge current
6A
Within a short time
Discharge end voltage
2.75V
Discharge cut-off voltage
Dimensions
18.29mm丨65.05mm
Diameter丨Height
Typical weight
49g
1.73 oz
Charge temperature range
+0 ~ +60°C
+50 ~ 110°F
Discharge temperature range
-10 ~ +45°C
-4 ~ +140°F
Storage temperature
-10 ~ +45°C
Within 3 months
