26650 LiFePO4 Battery Cells IFR26650 CB UL BIS

Large quantity in stock, Fresh and Grade A Cells

The 26650 LiFePO4 battery(Lithium Iron Phosphate), also known as IFR26650, is a model specification for cylindrical lithium batteries. The numbers in the model hold specific meanings: “26” represents the battery’s diameter of 26mm, “65” represents its height of 65mm, and “0” denotes its cylindrical shape. The 26650 LiFePO4 battery is primarily used in applications such as UPS batteries, AGV/AMR batteries, medical equipment, lead-acid replacement batteries, communication devices, and energy storage.

26650 LiFePO4 Cells Range

1. 26650-2400, 26650-2800, 26650-3000, 26650-3200, 26650-3300, 26650-4500
2. IFR26650-2500, IFR26650-3000, IFR26650-3300, IFR26650-3400, IFR26650-3500, IFR26650-3600, IFR26650-3800, IFR26650-3900, IFR26650-4000, IFR26650-4200, IFR26650-4500
3. IFR26650 3200mAh, IFR26650 3300mAh, IFR26650 3400mAh, IFR26650 3500mAh, IFR26650 3600mAh, IFR26650 3800mAh , IFR26650 4000mAh, IFR26650 4500mAh
4. IFR 22650 3.2V 2100mAh, IFR 26650 3.2V 3000mAh, IFR 26650 3.2V 3200mAh, IFR 26650 3.2V 3300mAh, IFR 26650 3.2V 3400mAh, IFR 26650 3.2V 3500mAh, IFR 26650 3.2V 3600mAh, IFR 26650 3.2V 3800mAh, IFR 26650 3.2V 4000mAh, IFR 26650 3.2V 4200mAh, IFR 26650 3.2V 4500mAh

Certificates and Test Reports

UL1642、UL2054，UL1973、IEC62133、CB/UL/BIS、UN38.3、MSDS、RoHS、REACH

26650 LiFePO4 High-rate Models

Model(s): IFR26650-25A, IFR26650-25B, IFR26650-26A, IFR26650-27A, IFR26650-27B, IFR26650-27C, IFR26650-28A, IFR26650-29A, IFR26650-30A, IFR26650-30B, IFR26650-30C, IFR26650-31A, IFR26650-32A, IFR26650-32B, LFP26650E-3200-11, IFR26650-32C, IFR26650-33A, IFR26650-34A, IFR26650-35A, IFR26650-35B, IFR26650-35C, IFR26650G2P, IFR26650P2800

26650 LiFePO4 High-energy Models

IFR26650 G1, IFR26650 G3, EXP-IFR26650G3
IFR26650-36A, IFR26650-37A, IFR26650-38A, LFP26650E-3750-11, IFR26650-40A
JGCFR26650-3200mAh-3.2V, HTCFR26650-3200mAh-3.2V, 26FC-10.24Wh 3.2V3200mAh
JGCFR26650-3400mAh-3.2V, IFR26650 JG, HTCFR26650-3400mAh-3.2V
JGCFR26650-3600mAh-3.2V, HTCFR26650-3600mAh-3.2V, 26FC-11.52Wh 3.2V3600mAh
JGCFR26650-3800mAh-3.2V, HTCFR26650-3800mAh-3.2V, 26FC-12.16Wh 3.2V3800mAh
JGCFR26650-4000mAh-3.2V, HTCFR26650-4000mAh-3.2V, 26FC-12.8Wh 3.2V4000mAh
JGCFR26650-4200mAh-3.2V, HTCFR26650-4200mAh-3.2V, 26FC-13.44Wh 3.2V4200mAh
JGCFR26650-4500mAh-3.2V, HTCFR26650-4500mAh-3.2V, 26FC-14.4Wh 3.2V4500mAh

Standard voltage of a single IFR26650 cell: 3.2V

Height: 65.3±0.3mm
Diameter: 26.3±0.2mm
AC resistance (1kHz): IFR26650-2500mah ≤ 6mΩ; IFR26650-3000mAh ≤ 10mΩ; IFR26650-3300mAh ≤ 20mΩ; IFR26650-3600mAh ≤ 20mΩ; IFR26650-3800mAh ≤ 20mΩ; IFR26650-4000mAh ≤ 20mΩ
Operating temperature: Charging temperature: 0°C-45°C; Discharging temperature: -20°C-60°C; Storage temperature: -20°C-45°C
Cycle life: (2500mah-3300mAh) (100% DOD) ≥ 3000; (3600mAh-4000mAh) (100% DOD) ≥ 2000

Supporting customized battery packs!

Ancoo specializes in designing and manufacturing custom 26650 battery packs that deliver exceptional performance in low-temperature environments, high-density applications, and mission-critical operations.

Advantages of the 26650 Lithium Iron Phosphate Battery

1. The 26650 LiFePO4 battery has a high volumetric energy density. Compared to lead-acid batteries, it offers approximately 1.5 times the energy density, meaning that for the same capacity, the 26650 LiFePO4 battery occupies around 2/3 of the volume of a lead-acid battery.
2. They are free of harmful heavy metals, making it safer and more environmentally friendly.
3. The IFR26650 battery has a high cycle life. Under 100% depth of discharge (DOD) conditions, it can endure over 2000 cycles, while IFR26650-2500mAh, IFR26650-3000mAh, and IFR26650-3300mAh can exceed 3000 cycles.

Application:

1. Energy storage applications:  Container energy storage, Solar home, Portable power station, SLA replacement, Emergency lighting etc.
2. Intelligent manufacturing applications: Inspection AGV, Fire AGV, Moving AGV, Robot
3. Light power applications: Golf trolley, E-bike, E-scooter, E-wheel chair, Low speed car, Tractor, Lawn mower;
4. Medical equipment applications: Wireless mobile medical carts, Medical workstation trolley, Electric doors and windows
5. Marine applications: Electric sightseeing boat, Search and rescue boat, Submarine
6. Lighting applications: Emergency light, Solar street light, Lawn light
