LG Li-ion cells

  • LG 18650 B4L 2600mAh 3.6V Lithium-ion Battery
  • LG 18650 B4L 2600mAh 3.6V Lithium-ion Battery
  • LG 18650 B4L 2600mAh 3.6V Lithium-ion Battery
LG 18650 B4L 2600mAh 3.6V Lithium-ion BatteryLG 18650 B4L 2600mAh 3.6V Lithium-ion BatteryLG 18650 B4L 2600mAh 3.6V Lithium-ion Battery

LG 18650 B4L 2600mAh 3.6V Lithium-ion Battery

MSDS UN38.3 RoHS CB  IEC62133
Nominal Capacity 2600mAh (0.2C discharge)
Minimum Capacity 3550mAh (0.2C discharge)
Charging Voltage 4.20±0.05 V
Normal Voltage 3.6V
Discharge Cut-off Voltage 2.5V
Charging Method CC-CV
Continuous Maximum Charge Current 2600mA
Continuous Maximum Discharge Current 5200mA
Cell Weight 45g
Cell Dimension 18*65mm
Operating Temperature Charge: 0 to 45°C
Discharge: -20 to 60°C
Storage Temperature 1 year: -20~25°C
3 months: -20~45°C
1 month: -20~60°C
