103450 Battery Cells

  • Panasonic 103450 2200mAh Battery Cells
  • Panasonic 103450 2200mAh Battery Cells
Panasonic 103450 2200mAh Battery CellsPanasonic 103450 2200mAh Battery Cells

Panasonic 103450 2200mAh Battery Cells

Panasonic 103450 2200mAh Li-ion Battery Cells

  1. >20K cells in stock! Fresh date code! Fast shipping by sea or air from China.
  2. We hold full Specification, SDS UN38.3 UL1642 BIS PSE CB IEC62133 Test Reports.


Specifications

5.1 Rated Capacity 2200mAh 0.44A discharge at 20°C
5.2 Capacity (Minimum) 2270mAh 0.454A discharge at 25°C
5.3 Capacity (Typical) 2350mAh Reference only
5.4 Nominal Voltage 3.6V 0.454A discharge
5.5 Discharging End Voltage 2.75V
5.6 Charging Current (Std.) 1.589A
5.7 Charging Voltage 4.20 ± 0.03V
5.8 Charging Time (Std.) 4.0 hours
5.9 Continuous Discharge Current (Max.) 4.54A, 0 ~ +40°C
5.10 Internal Resistance less than 100m AC impedance 1 kHz
5.11 Weight less than 38.6g
5.12 Operating Temperature: Charge +10 ~ +45°C Standard temperature range, Discharge -20 ~ +60°C


Panasonic 103450

Panasonic 103450 2200mAh
