EVE Li-ion Battery Cells

  • EVE INR18650/25P 2500mAh 3.6V 18650 High Power Li-ion Cells
  • EVE INR18650/25P 2500mAh 3.6V 18650 High Power Li-ion Cells
EVE INR18650/25P 2500mAh 3.6V 18650 High Power Li-ion CellsEVE INR18650/25P 2500mAh 3.6V 18650 High Power Li-ion Cells

EVE INR18650/25P 2500mAh 3.6V 18650 High Power Li-ion Cells

EVE INR18650/25P Cell Specifications

Nominal discharge capacity 2500mAh
Nominal voltage 3.6V
AC Impedance 1 kHz ≤15mΩ
Voltage range 4.2~2.5V
Weight ≤48g
Cell Surface Cut-off Temperature
Charge: 0 to +50℃ Discharge: -20 to +80℃
Standard charge current 1.25A
Max. continuous charge current 4.0A
Standard discharge current 0.5A
Max. continuous discharge current 30.0A
CC-CV, 1.25A to 4.2V, 100mA cut-off at 25℃; CC, 0.5A to 2.5V cut-off at 25℃


Safety Regulation: MSDS UN38.3 RoHS UL1642 CB IEC62133


Features & Benefits

• High rate charge & discharge

• Excellent wide temperature characteristics

• Automatic production and good consistency
