NCR18650GA, >100K in stock, fresh cells, fast shipping by air or ocean, contact us for a special offer.
Specification, SDS, UN38.3, UL1642, CB IEC62133 test reports and certificates are available.
| Type | Voltage (V) | Nominal capacity | Max. cont. current | Dimensions (mm) | Construction |
| UR18650RX | 3,6V | 2000mAh | 20A | ø 18,5×65,3 | Cylindrical |
| UR18650AY | 3,6V | 2150mAh | 4,3A | ø 18,3×64,9 | Cylindrical |
| UR18650AA | 3,6V | 2150mAh | 5A | ø 18,3×65,1 | Cylindrical |
| UR1865ZM2 | 3,6V | 2550mAh | 7.5A | ø 18,3×65,3 | Cylindrical |
| NCR18500A | 3,6V | 2040mAh | 4A | ø 18,5×49,5 | Cylindrical |
| NCR18650BD | 3,6V | 3030mAh | 10A | ø 18,5×65,3 | Cylindrical |
| NCR18650BF | 3,6V | 3250mAh | 4,87A | ø 18,5×65,3 | Cylindrical |
| NCR18650GA | 3,6V | 3350mAh | 8A | ø 18,5×65,3 | Cylindrical |
| Manufacturer |
Panasonic |
| Model |
GA |
| Size |
18650 |
|
Positive Terminal |
Flat Top |
| Nominal Capacity |
3450mAh |
| Continuous Discharge Rating (max) |
10A |
| Nominal Voltage |
3.6V |
| Maximum Voltage |
4.2V |
| Discharge cut-off Voltage |
2.5V |
| Protected |
No |
| Rechargeable |
Yes |
| Approx. Dimensions | 18.33mm x 65.08mm |
| Approx. Weight |
46.5g |
| Country of Origin |
China or Japan |
| Associated Names | GA6, GA6W |
| Data Specification Sheet | Panasonic NCR18650GA Datasheet |
